PHASED ARRAY MINIATURE INSTRUMENT

OEM-PA MINI

Best seller for Phased Array, OEM-PA Mini is a versatile and comprehensive board.

OEM-PA Mini is our flagship product for both Phased Array and Full-Matrix Capture(FMC).

Customize your very own Phased Array or FMC/TFM solution today !

Advanced Phased Array (Linear Scan, Sector Scan, DDF, DAC and Envelope).

High Performance Full-Matrix Capture (FMC) and Plane Wave Imaging (PWI)

Advanced Total Focusing Method (TFM) algorithms (Surface Adaptive, CWI, DWI, SAFT, Migration, Phase Coherence…etc.)



KEY BENEFITS

Advanced Digital I/O and Encoder support for robotics and high speed inspection automation.

Seamless integration with a very compact form factor allowing for on-scanner placement as well as perfect for within tightly integrated systems

Very-small form factor for easier and simple integration (3D models and 2D drawings available for customers)

Very-low power consumption for an advanced PA electronics making it possible for use with integrated battery solutions, smaller power supplies…etc

Low frequency Option: Ultrawide bandwidth opens door for more use cases like guided waves, concrete inspection and SHM applications

Excellent Support and Documentation! Speak directly to our engineers for integration needs, software training…etc

Specifications

Channels

16/16

16/64

16/128

16/256

32/32

32/128

32/256

64/64

64/128

64/256



Available Configurations

Pulse/Echo

Pitch & Catch

Trough Transmission (TTU)



Multi Instruments

Can be daisy chained to create a multi instrument or multi probe sytem

Best Analog Performance

Pulse :

100-150V Negative Square

PRF :

20kHz (higher in option)

Receiver Resolution :

14bits

Receiver Gain Range :

12-110dB

Bandwith :

50kHz to 20 MHz



Small form factor

Dimensions (L x W x H)

Min :

140 x 77 x 15 mm / 5.51 x 3.03 x 0.59 in

Max :

140 x 105 x 15 mm / 5.51 x 4.13 x 0.59 in

Weight :

< 250g / 0.55 lb

Low Power

Voltage :

12V

Power Consumption:

10W* (see datasheet for more details)



Communication

Datarate: 100 MB/s Full-Waveform A-scans
Gigabit Ethernet (TCP/IP)

Robust Software Development Kit (SDK)

Easy-to-use API Library. (C++, C#, LabVIEW, MATLAB, Python)

Linux Driver also available!

APPLICATIONS

CORROSION MAPPING

WELD INSPECTION

SUBSEA APPLICATIONS

SCanners, Crawlers, ROBOTICS

PHASED ARRAY, FMC/TFM, PLANE WAVE ImAGING (pwi) and more

OPTIONS AVAILABLE

io-fiber

I/O Fiber

Optical Fiber > 100m

Double or Single Ended

PoE+

Power Over Ethernet

+

Daisy Chained Electronics

For multi probe applications
