MULTI CHANNEL HIGH PERFORMANCE INSTRUMENT

OEM-MC2

Perfect for Thru-Transmission, research and other demanding ultrasound applications. Low Frequency option also opens door for applications like concrete inspection, guided wave and other structural health monitoring research.

OEM-MC2 connects to a PC via Gigabit Ethernet, and is powered with 12V. Its unique technology allows to acquire the A-scan with 27-bits of resolution, so analog gain is not required anymore (all the signal/dynamic from up to ±10V down to inside the noise floor is acquired and available for analysis in linear or logarithmic scale in the Software).

Each channel has a 400V pulser and a ±100V AWG (Arbitrary Waveform Generator) that permits to generate tone bursts, Chirps and Gaussian signals as well as any user defined waveform. Full parallel 8 channels allow to fit in any demanding application such as thick forged part as well as through transmission systems for bonding, composite and honeycomb inspections.



KEY BENEFITS

  • Unmatched Ultra-High performance
  • Analog Gain No longer required (acquires the full dynamic range at once with a 27-bit A-scan resolution)
  • Outstanding acquired dynamic range (156dB)
  • Full-parallel 8ch
  • 400V pulser as standard
  • ±100V AWG (Arbitrary Waveform Generator) in standard too

Specifications

Configurations

8 parallel channels per unit

Channel Mode

Full Parallel and / or Multiplexed

Available Configurations

Pulse/Echo

Pitch & Catch

Trough Transmission (TTU)



Multi Instruments

Can be daisy chained to create a multi instrument or multi probe sytem

Best Analog Performance

Pulse Type 1 :

8 Pulser up to 400 V (negative square)

Pulse Type 2 :

8 Pulser Bipolar ±100 V (burst, AWG in option)

PRF :

20kHz (higher in option)

Receiver Resolution :

27bits

Receiver Gain Range :

156dB

Bandwith :

50kHz to 20 MHz



Communication

LAN (TCP Protocol, Gigabit Ethernet)

Signal Processing

FIR Filter :

Up to 64 taps

AScan Resolution :

8,16,24,32bits, linear and log scale

AScan Sampling :

100MHz

Small form factor

Dimensions (L x W x H)

150 x 105 x 15 mm / 5.9 x 4.13 x 0.59 in

Weight :

< 250g / 0.55 lb

Low Power

Voltage :

12V

Power :

10W* (see datasheet for more details)



Robust Software Development Kit (SDK)

Easy-to-use API Library. (C++, C#, LabVIEW, MATLAB, Python)

Linux Driver also available!

APPLICATIONS

COMPOSITES

TROUGH TRANSMISSION

HEAVY INDUSTRY

DOUBLE TRANSMISSION

FORGED LARGE PARTS

OPTIONS AVAILABLE

io-fiber

I/O Fiber

Optical Fiber > 100m

Double or Single Ended

PoE+

Power Over Ethernet

+

Daisy Chained

For multi electronic

 or multi probe applications
